HS 4:1

Acrylic filler

Variants

ColourArt. No.CapacityQuantity per carton
grey22600,8 l + 0,2 l6
white 2252 0,8 l + 0,2 l6
black2253 0,8 l + 0,2 l 6

Gloss grade

matt
HS 4:1

Technical documentation

Weight/Volume Calculator

ml g
Primer
Hardener: 0 0
Total of mixture 0 0
Minimum thinner 0% 0 0
Total of mixture 0 0
Maximum thinner 0% 0 0
Total of mixture 0 0
Thinner value % 0 0
Warning: Value is not within the tolerance given by the manufacturer. (Min: , Max: ).
Total of mixture 0 0

Video

Description

Bicomponent acrylic filler with high solids content. Characterised by very filling properties, very high adhesion, good stability and good levelling on vertical surfaces. Very easy to apply.

Advantages

  • Easy to mix and apply.
  • Short hardening time.
  • Good isolating and filling properties.

Substrates

Acrylic primers can be applied over:

  • Bare steel and aluminum after matting and degreasing.
  • Zinc coated, galvanized steel after matting and degreasing.
  • Sanded polyester laminates (GFK/GRP).
  • Polyester putties.
  • Polyester primers.
  • Isolation primers.
  • Old finishes in good condition after matting and degreasing.

Good surface preparation is necessary for achieving best results.



Important informations

  • Przetrzeć odtłuścić

    degrease

  • Proporcje mieszania

    Mixing ratio
    4 : 1 + 15 ÷ 20%

  • Lepkość natryskowa

    Spraying viscosity
    30 ÷ 50 s / 20°C

  • Żywotność mieszanki

    Pot life
    60 min / 20°C

  • Liczba warstw

    2÷3 layer
    HVLP / RP
    ø1,5 ÷ 2,0 mm

  • Czas odparowania

    between layers
    5÷10 min

  • Czas odparowania

    before baking
    10 min

  • Czas utwardzania

    Hardening time
    3÷4 h / 20°C
    30 min / 60°C

  • Szlifowanie na sucho

    P320÷P500
    P280÷P320

  • Szlifowanie na mokro

    P600÷P1000
    P800÷P1000

Application process

  • Zastosowanie
  • Use

    For car repairs as a filling or grounding filler.

  • Proporcje mieszania
  • Mixing ratio by volume

    Filler: 4
    Hardener: 1
    Thinner: 15÷20%

    Stir thoroughly until achieving homogenous mixture.

  • Lepkość natryskowa
  • Spraying viscosity

    30÷50 seconds at 20°C

  • Żywotność mieszanki
  • Pot life

    approx. 60 min. at 20°C

  • Liczba warstw
  • Number of layers

    2÷3 layers of 150÷300µm thickness

    RP gun parameters:
    Nozzle: 1,6÷2,0 mm, Pressure: 2,0÷2,2 bar
    HVLP gun parameters:
    Nozzle: 1,5÷1,9 mm; Pressure: 2,0 bar

  • Czas odparowania
  • Evaporation time

    Between the layers: approx. 5÷10 minutes
    Before baking: approx. 10 minutes

    Evaporation time depends on the temperature and the number of layers.

  • Czas utwardzania
  • Hardening time

    Approx. 3÷4 hours at 20°C
    Approx. 30 min. at 60°C

    Temperature below 20°C significantly increases the hardening time.

  • Suszenie promieniem IR
  • IR drying

    10÷15 minutes of short waves for the thickness of 150÷250 µm. Do not exceed 60°C. Use as recommended by the equipment manufacturer. Wait about 10 minutes before starting the heater drying.

  • Szlifowanie na sucho
  • Dry sanding

    By machine P320÷P500
    By hand P320÷P500

  • Szlifowanie na mokro
  • Wet sanding

    By machine P600÷P1000
    By hand P800÷P1000

  • Informacja
  • Further work

    2K acrylic fillers can be directly over coated with:

    • 2K acryl top coats
    • 1K base coats
  • Informacja
  • General notes
    • Do not exceed recommended doses of hardener!
    • The best repair results can be achieved at room temperature. Temperature in body shop and temperature of a product should be the same.
    • When working with 2K products, it is recommended to use personal protection equipment. Protect the eyes and respiratory system.
    • Clean the guns and equipment immediately after use.
    • The rooms should be well ventilated.

    Caution: To maintain safety, always follow the instructions given in the MSDS for the products.
